Session summary This session covered the Karpathy's whole micrograd video. The first half builds a computation graph out of a plain math expression and teaches backpropagation over it. The second half builds a small neural network (Neuron → Layer → MLP) on top of that same engine. By the end I could follow the full hierarchy: values → neurons → layers → MLP, which is the hardest conceptual jump in the video.
Part 1 — The computation graph & backprop
The Value object (the building block)
Every single number in the graph is a Value object. Each one stores:
data— the actual number from the forward pass.grad— the derivative ∂L∂this\frac{\partial L}{\partial \text{this}} ∂this∂L, filled in during the backward pass (starts at 0).- the operation that created it (
+,*,tanh, …). - pointers to its parent nodes — the Values that produced it.
Why the parent pointers matter Those pointers are what let backprop walk the graph backward. Without them there's no trail to follow from the output back to the inputs.
Building the graph
When I write d = a * b + c, I’m not just getting a number — each operation creates a new Value node that remembers which operation made it and who its parents were. So a * b is a new node that knows “I was born from a multiply, my parents are a and b.”
That stored operation is exactly what tells backprop which local derivative rule to apply later.
Local derivatives + the chain rule
The key insight: each node only needs its own local derivative. No node ever needs the big picture.
| Operation | What it does to the incoming gradient |
|---|---|
+ (add) | passes the gradient straight through, unchanged |
* (multiply) | swaps in the other input |
tanh | multiplies by 1−tanh2(x)1 - \tanh^2(x) 1−tanh2(x) |
The chain rule then stitches all those local pieces together into the full derivative. Local rule × what came from behind = gradient at this node.
Forward pass vs backward pass
Getting the gradient is a two-pass process:
- Forward pass — feed inputs in, compute left → right to the final output. The graph records every operation and value. Now I have all the
data, but no gradients yet. - Backward pass (backprop) — start at the very end, seed with
grad = 1(∂L∂L=1\frac{\partial L}{\partial L} = 1 ∂L∂L=1), then walk backward, applying each node’s local rule × the incoming gradient. This fills ingradon every node.
The "1" that seeds backprop It's
L.grad = 1because the output's derivative with respect to itself is 1. It is not the loss data value.
The manual “nudge” demo (gradient descent, previewed)
Before the neural net, Karpathy does a mini-demo: run backward to get each input’s gradient, then nudge every input a little in the direction of its gradient — and the output goes up, just as the gradients predicted.
The update rule for each input:
new data=old data+(step size×grad)\text{new data} = \text{old data} + (\text{step size} \times \text{grad})new data=old data+(step size×grad)
Why multiply by the gradient instead of just using its sign?
- Size matters, not just direction — a big gradient means a strong effect, so that input moves more.
- The sign falls out automatically — a negative grad makes the term negative, so the input goes down on its own. I never have to reason about signs; the math handles direction and strength in one move.
This is the whole idea of learning in miniature: gradient tells direction, small step moves you that way. (In real training we step in the opposite direction to make loss go down — that’s gradient descent.)
Part 2 — From one neuron to a network
The neuron (a.k.a. perceptron)
A single artificial neuron:
y=tanh (∑iwixi+b)y = \tanh!\left(\sum_i w_i x_i + b\right)y=tanh(i∑wixi+b)
- multiply each input by its weight
- sum them all
- add a bias
- squash through an activation (
tanh)
How many Values does a neuron hold? One weight per input, plus exactly one bias. So a neuron with 3 inputs holds 4 Values (3 weights + 1 bias); with 2 inputs, 3 Values. Not just one.
Inside, the neuron builds the same multiply-then-add graph from Part 1 — w1x1+w2x2+⋯+bw_1x_1 + w_2x_2 + \dots + b w1x1+w2x2+⋯+b — feeding into a final tanh node. Same building blocks I already know.
ValuevsNeuron— two different levelsValue= the low-level graph node (each weight, each intermediate result).Neuron= a container that owns a bundle of Values (its weights + bias). The neuron doesn't replace Value; it holds a handful of them.
Activation functions
tanh squashes to [−1,1][-1, 1] [−1,1]; sigmoid squashes to [0,1][0, 1] [0,1]. But squashing the range isn’t the real reason we use them.
The real job: non-linearity Without an activation, stacking layers is pointless — a chain of linear steps collapses into one linear step, so the network can only draw straight lines. The activation adds a bend at each layer, and that's what lets the network learn curves and complicated shapes.
For following the video, “it squashes into a range” is a fine working description — just keep the footnote that the deeper purpose is the bend.
The three classes: Neuron → Layer → MLP
Boxes inside boxes. Each class has the same three methods.
Neuron
- constructor — creates its weights + bias as random Values.
__call__— takes inputs, does w⋅x+bw \cdot x + b w⋅x+b thentanh, returns the result.parameters()— returns its weights + bias in one list.
Layer = a row of neurons side by side.
- constructor — you say how many inputs and how many neurons; it builds them.
__call__— feeds the same inputs to every neuron, collects each neuron’s one output into a list. → 5 neurons ⇒ 5 outputs.parameters()— gathers weights + biases from all its neurons.
MLP (Multi-Layer Perceptron) = a stack of layers in a row.
- constructor — you give the sizes; it builds all the layers.
__call__— passes inputs through each layer in turn; one layer’s outputs become the next layer’s inputs; the last layer’s output is the final answer.parameters()— gathers every weight + bias from every layer.
The hierarchy MLP is a list of layers · Layer is a list of neurons · Neuron is a bundle of Values. The outputs of one layer feed the next, all the way through.
__call__ — the Python trick that makes it elegant
__call__ is a real built-in Python dunder (double-underscore) method, not something Karpathy invented. Defining it makes an instance callable like a function:
python
n = Neuron(2)
out = n(x) # secretly runs n.__call__(x)Because of this, a Layer can call each neuron with neuron(x), and the MLP can call each layer the same way. Everything becomes callable, so the code reads like data flowing through a chain of functions — calls inside calls, a manager passing work down to each worker.
parameters() — why it exists
During training I need to grab every weight and bias so I can nudge each one. parameters() is the convenient “give me everything I’m allowed to tune” list, gathered up the hierarchy (neuron → layer → MLP).
